12V Ceramic Heating Elements
  • 12V Ceramic Heating Elements - 0 12V Ceramic Heating Elements - 0
  • 12V Ceramic Heating Elements - 1 12V Ceramic Heating Elements - 1
  • 12V Ceramic Heating Elements - 2 12V Ceramic Heating Elements - 2
  • 12V Ceramic Heating Elements - 3 12V Ceramic Heating Elements - 3
  • 12V Ceramic Heating Elements - 4 12V Ceramic Heating Elements - 4

12V Ceramic Heating Elements

GRWAY® 12V Ceramic Heating Elements were developed based on ceramic lamination technologies, which are mainly used for automotive and various industrial applications such as soldering iron, kerosene & gas equipment, pellet burner and water heating.

Model:7788

Send Inquiry

PDF Download

Product Description

12V Ceramic Heating Elements

GRWAY® 12V Ceramic Heating Elements were developed based on ceramic lamination technologies, which are mainly used for automotive and various industrial applications such as soldering iron, kerosene & gas equipment, pellet burner and water heating.


Process of 12V Ceramic Heating Elements

First, painting the high melting point metal (tungsten or molybdenum manganese) paste on to the Al2O3 casting briquette in coordinate to the circuit design, then another layer of sintering additives. After that, repeating the process to build multiple layers. Then, they are sintered together under 1600 °C hydrogen gas environment. Finally, nickel leads are brazed at 800 °C onto the metal end and put on with Teflon sleeve, which make it a MCH heating element.

Internal Heating elements are protected from oxidation due to sintering into one-piece ceramic body structure.


Material Properties of 12V Ceramic Heating Elements

Item

Inspection Condition

Unit

Standard

Color



White

Density


g/cm3

3.7

Water absorption


%

0

Average grain size


μm

3~5

Hardness


Load 4.9N

4.9N

GPa

≥15

Flexural strength


MPa

≥274

Linear expansion coefficient

20~500℃

1×10-6mm/℃

6.5~7.5

20~800℃

6.5~8.0

Thermal conductivity

20℃

W/(m·K)

≥20.9

Specific heat


kJ/(kg·K)

≥0.8

Insulation strength


KV/mm

≥12

Volume resistivity

20℃

Ohm.cm

≥1014

300℃

≥1011

500℃

≥109

Permittivity

1MHz


9~10

Dielectric loss tangent

1MHz


≤3×10-4

Surface roughness


μm

0.3~0.8


Features of 12V Ceramic Heating Elements

It is a new type of high efficient heater, which can save more than 20%-30% power effect compare to PTC ceramic heaters. Our alumina ceramic heaters have many excellent features:

High power density, excellent thermal efficiency

Rapid heating, non-hot spot temperature distribution

High temperature, small size, light weight


Parameter of Cordless Soldering Iron Heating Element

Heater Name

12V Ceramic Heating Element

Working Voltage

12V

Working Power

15W~90W

Dimension

Length 60mm* diameter 3.8mm or Customization

Leads

Nickel wires

Working Temperature

400~500℃

Insulation Sleeve

Accordingly


Application

Electronic cigarette, vaporizers, coffee machine, Intelligent toilet, instant electric kettle, instant water heater, intelligent basin faucet; hair straightener, hair curler, car exhaust oxide sensor, heating for industry device, ultrasonic heating element, mold heater, medical equipment heater ,air heater, small household appliances, etc......


FAQ

1. How long for the delivery time of ceramic heaters?

In general, 1-30days according stock situation for already models,

New customized heating elements will be delivered as negotiation with our clients.


2. Can ceramic heating core be customized , such as shape or dimension?

Surely, heating core is welcome customized as your need.


3. May i know which payment will be accepted by your company?

So far 100%T/T against PO., or negotiation.
