  • Ceramic Element Heater For Milwaukee Soldering Iron - 0 Ceramic Element Heater For Milwaukee Soldering Iron - 0
  • Ceramic Element Heater For Milwaukee Soldering Iron - 1 Ceramic Element Heater For Milwaukee Soldering Iron - 1
  • Ceramic Element Heater For Milwaukee Soldering Iron - 2 Ceramic Element Heater For Milwaukee Soldering Iron - 2
  • Ceramic Element Heater For Milwaukee Soldering Iron - 3 Ceramic Element Heater For Milwaukee Soldering Iron - 3

Ceramic Element Heater For Milwaukee Soldering Iron

GRWAY® Ceramic Element Heater For Milwaukee Soldering Iron have characteristic design & practical performance & competitive price, for more information on the Ceramic Element Heater For Milwaukee Soldering Iron, please feel free to contact us.

Model:E6038FR

Send Inquiry

PDF Download

Product Description

Ceramic Element Heater For Milwaukee Soldering Iron

GRWAY® Ceramic Element Heater For Milwaukee Soldering Iron were developed based on ceramic lamination technologies, which are mainly used for automotive and various industrial applications such as soldering iron, kerosene & gas equipment, pellet burner and water heating.


Material Properties of 95% Al2O3 Alumina ceramic

Item

Inspection Condition

Unit

Standard

Color





White

Density



g/cm3

3.7

Water absorption



%

0

Average grain size



μm

3~5

Hardness



Load 4.9N

 4.9N

GPa

≥15

Flexural strength



MPa

≥274

Linear expansion coefficient

20~500℃

1×10-6mm/℃

6.5~7.5

20~800℃

6.5~8.0

Thermal conductivity

20℃

W/(m·K)

≥20.9

Specific heat



kJ/(kg·K)

≥0.8

Insulation strength



KV/mm

≥12

Volume resistivity

20℃

Ohm.cm

≥1014

300℃

≥1011

500℃

≥109

Permittivity

1MHz



9~10

Dielectric loss tangent

1MHz



≤3×10-4

Surface roughness



μm

0.3~0.8



Features of Ceramic Element Heater For Milwaukee Soldering Iron

Ceramic Element Heater For Milwaukee Soldering Iron is a new type of high efficient heating elements, which can save more than 20%-30% power effect compare to PTC ceramic heaters. Our alumina ceramic heaters have many excellent features:

1.High power density, excellent thermal efficiency

2.Rapid heating, non-hot spot temperature distribution

3.High temperature, small size, light weight

4.Excellent insulation (the leakage current is < 0.5 mA under voltage 4500V/1S testing with no breakdown)

5.High reliability, stable resistance, no electric noise

6.Good chemical resistance full compliance with EU RoHS (no lead, cadmium, mercury, hexavalent chromium,  PCBS, and other harmful substances)

No charge on surface and safe to touch.


Parameter of Aluminum Heater Element


Application

The aluminum ceramic heaters are widely used in all kinds of applications nowadays, such as: intelligent bidet seat, electric water heater, medical machine, dryer, electric heating splint, electric iron, vacuum flask, electric cooker, electric bonder, capper, UTR cylinder condensation-proofer, IR physiotherapy equipment, intravenous injection heating, quick food heating, mini thermostatic bath for special crystal parts, automatic exhaust oxidation sensors, industrial equipment heater, and small heating appliance, etc.


Packing and Delivery

The suitable packing should be taken to avoid the breakage and contamination during the shipment.

If the products are not sufficient to full of carton,buffer material can be used to ensure the shipping safety.
