Igniter For Lighting

GRWAY® Igniter For Lighting are produced by implementing ceramic lamination processes. As the professional manufacture, we would like to provide you Igniter For Lighting. And we will offer you the best after-sale service and timely delivery.

Model:G90105

Send Inquiry

PDF DownLoad

Product Description

Igniter For Lighting

GRWAY® Igniter For Lighting are produced by implementing ceramic lamination processes. Due to the compactness, high power and rapid heating speed.Ceramic Heater can provide higher reliability than ever before. Mainly applications include use as innovative types of heaters in the automotive, medical and semiconductor industries.


Parameter of GREENWAY Igniter For Lighting

Power Source

Electric

Brand Name

GREENWAY

Weight (N.W)

50g

Certificate

Rohs/Reach

Max Temperature

1050 deg C

Main Material

95% aluminum ceramic

Flange

Ceramic flange or copper thread

Dimension

94*10.5mm /108mm*11.5mm OR Customized

Power

150W~350W

Warranty

13 months

Ignition Time

60-90 seconds

Wire Length

50cm or accordingly

OEM/ODM

AVAILABLE


Features of Igniter For Lighting

High power density, excellent thermal efficiency

Rapid heating, non-hot spot temperature distribution

High temperature, small size, light weight

Excellent insulation (the leakage current is < 0.5 mA under voltage 4500V/1S testing with no breakdown)

High reliability, stable resistance, no electric noise

Good chemical resistance

full compliance with EU RoHS (no lead, cadmium, mercury, hexavalent chromium, PCBS, and other harmful substances)

No charge on surface and safe to touch.


GREENWAY Igniter For Lighting Application

Wood pellet stove

Wood pellet boiler

Wood pellet burner

Wood chips burner

Straw burner

Other biomass burner


Inspection standard

To ensure the quality of products, the in-process inspection and sampling inspection should be taken which based on the regulation of National GB/T 2828-2003.

Part 1.Sampling inspection of AQL standard.


In-process inspection VS Sampling Inspection

Inspection items

In-process inspection

QC sampling inspection

Inspection level

Acceptable quality level(AQL)

Appearance

100% inspection

1.0

Straightness

100% inspection

S-4

1.0

Dimension

100% inspection

1.0

Power-on Test

100% inspection

0.40

Dielectric Strength

100% inspection

0.65


Packing and Delivery

Box;Carton;
Delivery with Express such as TNT/DHL/Fedex and UPS

Lead time:1-35 working days


FAQ

1. Q:Can ceramic heating core be customized , such as shape or dimension?

A:Surely, heating core is welcome customized as your need.


2. Q: May i know which payment will be accepted by your company?

A: So far 100%T/T against PO., or negotiation.


3. Q:About the after-sale service, how can you solve the problems occurred of your overseas customer in time?

A:The warranty of our ceramic heater is normally 13 months, during this period, we will arrange the international express immediately(or later batch), to make sure the replace parts to be delivered as soon as possible.
